Edit Distance Algorithm: Categorification

Categories for the Working Programmers

Part 2: NNG graph of words with Edit Distance form a Path Category

(fully coded)

Dara O Shayda
dara@compclassnotes.com

In[]:=

DateObject[]

Out[]=

Mon 8 Jun 2026 18:13:59GMT+1

Abstract

In part 1 of Edit Distance we learned how to code the distance metric and the corresponding NNG (Nearest Neighbor Graph) and conceptualized this graph as a space for the words to reside within. Now in part 2, learn how to code to extend this NNG into a Path Category NNG and construct codexplanations for the properties of a category. Finally we learn to construct an EndoFunctor called StringTrim, from the new word-Path category to itself, such that its Identity Natural Transformation is actually a single familiar computational function which trims off repeated tokens from the beginning and the end of a word. We hope the programmers can code a Eureka moment to understand that all that which we program are actually natural transformations between some categories.

codexplain: code explain as in explain something by its construction code.

Live Notebooks:
Part 2: https://www.wolframcloud.com/obj/ccn2/Published/edit_distance_note2.nb
Part 1: https://www.wolframcloud.com/obj/ccn2/Published/edit_distance_note1.nb

CCN NODE:
Part 2: https://discuss.compclassnotes.com/t/edit-distance-algorithm-categorification/274
Part 1: https://discuss.compclassnotes.com/t/edit-distance-algorithm/268

 To find hidden scripts, click on either vertical bars to toggle to view or hide the code. See below.

In[]:=

Clear[editDistance];myEditDistance[s0_,t0_]:=Module[{m,n,s,t,d,d2,substitutionCost},(*foralliandj,d[i,j]willholdthedistancebetweenthefirsticharactersofsandthefirstjcharactersoftnotethatdhas(m+1)*(n+1)values*)m=StringLength[s0];n=StringLength[t0];d=ConstantArray[0,{m+1,n+1}];(*1-indexedarrays*)s=StringSplit[s0,""];t=StringSplit[t0,""];(*sourceprefixescanbetransformedintoemptystringbydroppingallcharacters*)(*1-indexedmatrix*)Do[d[[i,1]]=i-1,{i,2,m+1}];(*targetprefixescanbereachedfromemptysourceprefixbyinsertingeverycharacter*)Do[d[[1,j]]=j-1,{j,2,n+1}];substitutionCost=0;Do[If[s[[i-1]]==t[[j-1]],substitutionCost=0,substitutionCost=1];d[[i,j]]=Min@{(d[[i-1,j]]+1),(*deletion*)(d[[i,j-1]]+1),(*insertion*)(d[[i-1,j-1]]+substitutionCost)(*substitution*)},{j,2,n+1},{i,2,m+1}];d2=Prepend[Transpose@d,Join[{""},StringSplit[s0,""]]];d2=Prepend[Transpose@d2,Join[{"",""},StringSplit[t0,""]]];d2[[Dimensions[d2][[1]],Dimensions[d2][[2]]]]=(Highlighted@d2[[Dimensions[d2][[1]],Dimensions[d2][[2]]]]);Clear[];=d2//MatrixForm;d[[m+1,n+1]]];

NearestNeighborGraph[ ]

Words, and their similars reside in graphs called the Nearest Neighbor Graphs (NNG) [3]. Let us construct one for one single base word namely

"mesh"

(*CommentouttheSeedRandomtovariatethewordselections*)SeedRandom[ToString@myEditDistance];dict=DeleteDuplicates@Join[RandomSample[Nearest[DictionaryLookup[]]["mesh",1000],10],{"mesh","me"}];nng=NearestNeighborGraph[dict,{3,3},VertexLabels->"Name",DistanceFunction->myEditDistance,ImageSize->500,DirectedEdgesTrue,GraphLayout->{"SpringEmbedding","Rotation"0Degree}]

Out[]=

In[]:=

edges=EdgeList@nng

Out[]=

{dimesekes,dimesmesh,dimesme,beyseff,beysheed,beysbean,effbeys,effheed,effgas,heedbeys,heedmend,heedheap,gasbeys,gaseff,gasheap,mendheed,mendmesh,mendme,heapbeys,heapheed,heapbean,mushedmesh,beanbeys,beaneff,beanheap,ekesdimes,ekesbeys,ekeseff,meshdimes,meshmend,meshme,medimes,memend,memesh}

In[]:=

nnglables=Table[edges[[i]]Subscript["→",i],{i,1,Length@edges}]

Out[]=

{dimesekes

→

,dimesmesh

→

,dimesme

→

,beyseff

→

,beysheed

→

,beysbean

→

,effbeys

→

,effheed

→

,effgas

→

,heedbeys

→

,heedmend

→

,heedheap

→

,gasbeys

→

,gaseff

→

,gasheap

→

,mendheed

→

,mendmesh

→

,mendme

→

,heapbeys

→

,heapheed

→

,heapbean

→

,mushedmesh

→

,beanbeys

→

,beaneff

→

,beanheap

→

,ekesdimes

→

,ekesbeys

→

,ekeseff

→

,meshdimes

→

,meshmend

→

,meshme

→

,medimes

→

,memend

→

,memesh

→

}

In[]:=

nng2=Graph[DeleteDuplicates@Flatten@Map[{#[[1]],#[[2]]}&,edges],edges,VertexLabels->"Name",EdgeLabelsnnglables,GraphLayout->{"SpringEmbedding","Rotation"0Degree},ImageSize->550]

Out[]=

Q: Why

"mushed"

has no incoming edges/arrows?

Write a tiny bit of code to codexplanation the answer this question:

In[]:=

VertexInComponent[nng,{"mushed"},{1}]

Out[]=

{}

codexplain: code explain as in explain something with its construction code.

In[]:=

VertexOutComponent[nng,{"mushed"},{1}]

Out[]=

{mesh}

● Recall the definition of an edge between two vertices in a NNG graph:

{1} here indicates the distance in the number of edges in nng.

and the particular implementation of the NNG used these 3 and discarded the rest.

Visualizations: Subgraphs

Visualizations: Paths

Visualizations: All Path between two vertices

Categorification

Digression: T, ξ

Example

The usual bracketed expressions:

Why? Move away from Function Paradigm

This is how a Piecewise [ ] function is used; try to use it for hundreds to thousands of terms e.g. solutions to FEM equations:

Vector Dot Product Paradigm

Compute two vectors 1 and v2:

Compute their dot product and that computes an algebraic product like version of the piecewise function!

Monad メカ (Mechanation)

Mecha Ref[13].

Let us codexplain a few examples.

ξ : Expressions

ξ : Strings

● You already know these functions in Wolfram programming language namely for Expressions or Strings:

T is Level[ ] or StringSplit[ ]
ξ is Total[ ] or StringJoin[ ]

Write a bit of code to study ϕ :

● For strings we introduce a bit of tease which surprisingly is not provided in the Wolfram language! As it should have been:

Treat String like an Array

NNG Categorification: Path Category

Example

Sample Morphisms (paths)

Composition

Bird’s Eye View

Corollary: myEditDistance [ ] metric and corresponding NNG graph form a Path Category.

● This indicates that these particular Path Categories are similar structures appearing independent of how the strings and their metrics were defined.

● Post construction, the sets actually do not play any roles.

We call this categorification of words.

Functors

● A Functor, between two categories, is a tuple of two maps which combined serve similar to a homomorphism, preserving the similarities between two categories

● An EndoFunctor, from a category to itself, preserves the self-similarity or the category’s inner-symmetries

Definition

● The object function F which assigns to each object X of C an object F(X) of D

η Natural Transformations: StringTrim[ ]

Identity Natural Transformation

You might note the path or morphism is shrunken
