# Transfer Function for Continuous-Mode Boost Converter

Transfer Function for Continuous-Mode Boost Converter

This Demonstration models the averaged transfer function of a continuous-mode boost power converter. The pole and zero locations are plotted on the complex plane, and the gain and phase are shown in the frequency domain. Note how the zero location changes as you vary the inductor current direction and magnitude.
