Step Response with a P Controller

proportional gain

k

p

1

This is a step response for a unity feedback system with proportional gain

k

p

. The plant is second order with poles at -1 and -2, unity DC gain, and no zeros. Adjust

k

p

to view the effect of the proportional gain on the step response of the closed loop system.
