Pressure-Temperature Diagram for a Binary Mixture

​
ethane mole fraction
0.2
show all curves
This Demonstration shows a pressure-temperature (
P
-
T
) diagram for an ethane/heptane mixture in vapor-liquid equilibrium. The single-component plots of saturation pressure as a function of temperature are shown, as are
P
-
T
curves at six different ethane mole fractions; the liquid curve is shown in blue, the vapor curve in green. Use the slider to display an additional
P
-
T
curve (dashed) at the ethane mole fraction selected. The critical locus (black curve) represents the critical points for all mixtures of ethane and heptane. Uncheck "show all curves" to show only the selected mole fraction and the pure components.
