Nomography for Beginners

​
20
50
100
500
1000
R
1
,
R
2
scale maximum
A nomogram (or nomograph) is a two-dimensional diagram designed to quickly approximate the computation of a function.
Nomography was invented by the French mathematicians Massau and Ocagne in 1889 and used until the 1970s to provide scientists with fast graphical calculations with reasonable precision.
Basic nomograms are parallel-scale or concurrent-scale nomograms but many other types exist.
This Demonstration shows a simple concurrent-scale nomogram used to calculate the result of formulas of the type
1
R
3
=
1
R
2
+
1
R
1
(resistances in parallel, spring constants, lens focal lengths, or capacitances in series, etc.).
Use the locators to move the red line, called the index line or isopleth, that goes from
R
1
to
R
2
. The result is read at the intersection of the isopleth with the
R
3
scale.
