RegionNearest gives the point in a region nearest to a point outside the region. The following function finds the points in two regions nearest the other region and the distance between the points. The arguments are the two regions, a starting point in the first region, and a tolerance, since the calculation may be iterative.
In[]:=
min[reg1_,reg2_,reg1StartPoint_List,tolerance_]:=​​Block[{rn1,rn2,pt1,pt2},​​rn1=RegionNearest[N@reg1];​​rn2=RegionNearest[N@reg2];​​iter[pt_List]:=rn1[rn2[pt]];​​pt1=FixedPoint[iter,reg1StartPoint,SameTest->(Norm[#2-#1]<tolerance&)];​​pt2=rn2[pt1];​​{Norm[pt1-pt2],{pt1,pt2}}​​]

An Ellipse and a Polygon

In[]:=
reg1=Disk[{-2,0},{2/3,4/3}];
In[]:=
reg2=RegularPolygon[{2,3},{1,Pi/5},3];
In[]:=
sln=minreg1,reg2,{-2,0},
-6
10

Out[]=
{3.54806,{{-1.62206,1.09837},{1.24838,3.18386}}}
In[]:=
Show[​​Graphics@{Opacity[0.2],reg1},​​Graphics@{Opacity[0.2],reg2},​​Graphics@Line[sln[[2]]],​​Frame->True,​​ImageSize->Small​​]
Out[]=

A Convex Polygon and a Non-Convex Polygon

In[]:=
p1=Polygon[CirclePoints[3]];
In[]:=
p2=Polygon[{{2,-1},{4,-1},{4,1},{2,2},{3,0}}];
In[]:=
sln=min[p1,p2,{0,0},
-6
10
]
Out[]=
{1.23931,{{0.866025,-0.5},{2.,-1.}}}
In[]:=
Show[​​Graphics@{Opacity[0.2],{p1,p2}},​​Graphics@Line[sln[[2]]],​​Frame->True,​​ImageSize->Small​​]
Out[]=

An Ellipse and a Non-Convex Polygon

In[]:=
sln=minreg1,p2,{-2,0},
-6
10

Out[]=
{3.41683,{{-1.36869,-0.428448},{2.,-1.}}}
In[]:=
Show[​​Graphics@{Opacity[0.2],{reg1,p2}},​​Graphics@Line[sln[[2]]],​​Frame->True,​​ImageSize->Small​​]
Out[]=

CITE THIS NOTEBOOK

Extending RegionNearest to find nearest two points in two regions and their distance​
by Frank Kampas​
Wolfram Community, STAFF PICKS, October 13, 2024
​https://community.wolfram.com/groups/-/m/t/3297016
